Description
PR 2231D
Reliable trip signal amplification for driving circuit breaker trip coils from protective relay outputs
| Brand | PR |
| Model | 2231D |
| Voltage | 125/250V DC |
| Country of Origin | USA |
| Weight | 0.5 kg |
| Dimensions | 70x90x60 mm |
| Warranty | 6 months |
| Certifications | UL, CSA |
| SKU / MPN | 2231D |
| What’s in the box | Trip amplifier unit, mounting hardware, instruction manual, wiring diagram |
| Trip Output Current | 5A at 125/250V DC |
| Input Signal | Low-level relay contact output |
| Response Time | < 10 ms |
| Mounting Type | DIN Rail / Panel Mount |
| Contact Rating | 5A continuous, 15A inrush |
| Operating Temperature | -10°C to +55°C |
Key benefits: High trip output current, fast response time, compact DIN rail design, UL and CSA certified, compatible with most protective relays
Typical applications: Substation protection relay systems, circuit breaker trip coil driving, power distribution panels, industrial motor control centers
Lifecycle: Active product, long-term availability
