Description
TR Encoder CDH75M-00003 High Precision Rotary Sensor
High accuracy rotary position sensing with robust design for industrial automation.
| Brand | TR Encoder |
| Model | CDH75M-00003 |
| Voltage | 5 V DC |
| Country of Origin | Germany |
| Weight | 150 g |
| Dimensions | 75 mm diameter x 40 mm height |
| Warranty | 2 years |
| Certifications | CE, RoHS |
| SKU / MPN | CDH75M-00003 |
| What’s in the box | Rotary sensor, mounting hardware, user manual |
| Resolution | 12-bit (4096 steps per revolution) |
| Output Type | Incremental quadrature |
| Operating Temperature | -40°C to +85°C |
| Protection Rating | IP65 |
| Shaft Type | Solid stainless steel |
| Max Speed | 6000 RPM |
| Interface | TTL compatible |
Key benefits: Provides precise angular position feedback with high durability and resistance to harsh environments, ensuring reliable performance in demanding industrial applications.
Typical applications: Suitable for robotics, CNC machinery, automation systems, and motor control where accurate rotary position sensing is critical.
Order number: TR Encoder CDH75M-00003 High Precision Rotary Sensor
Lifecycle: Active
Documentation: Datasheet and installation guide available upon request
