Description
Heidenhain ROD 426 2500 03S12-03 376846-V1
High-precision incremental encoder with 2500 lines/rev for demanding motion control in machine tools and automation systems
| Brand | Heidenhain |
| Model | ROD 426 2500 03S12-03 376846-V1 |
| Voltage | 5V DC ±5% |
| Country of Origin | Germany |
| Weight | 0.45 kg |
| Dimensions | 58 mm diameter x 66 mm length |
| Certifications | CE, UL, RoHS |
| SKU / MPN | 376846-V1 |
| What’s in the box | Incremental encoder with integrated cable, mounting clamp, user manual |
| Resolution | 2500 lines per revolution |
| Output Signal | TTL square-wave (A, B, reference pulse) |
| Max. Operating Frequency | 300 kHz |
| Shaft Type | Solid shaft, 6 mm diameter |
| Protection Class | IP40 (IP64 with optional sealing) |
| Temperature Range | -10°C to +70°C |
Key benefits: Excellent signal quality, robust mechanical design, easy installation, long-term reliability, compatible with common controllers
Typical applications: CNC machine tools, servo motor feedback, linear axis measurement, robotic joint positioning, high-speed printing presses
Lifecycle: Active, supported for 10+ years
