Description
VAT 24432-KA41-BDF1
High-performance metal-sealed vacuum gate valve designed for demanding semiconductor and thin-film coating applications requiring ultra-high vacuum integrity
| Brand | VAT |
| Model | 24432-KA41-BDF1 |
| Voltage | 4-6 bar (pneumatic actuation) |
| Country of Origin | Switzerland |
| Weight | 9.5 kg |
| Dimensions | 210x165x110 mm |
| Warranty | 6 months |
| Certifications | CE, SEMI S2, ISO 9001 |
| SKU / MPN | 24432-KA41-BDF1 |
| What’s in the box | Vacuum gate valve unit, pneumatic actuator, mounting hardware, user manual, leak test certificate |
| Connection Type | CF flange (ConFlat) |
| Pressure Range | 10^-9 mbar to atmospheric |
| Bake Temperature | Up to 200°C |
| Actuation | Double-acting pneumatic |
| Leak Rate | < 1×10^-10 mbar·l/s (He) |
| Body Material | 316L Stainless Steel |
Key benefits: Ultra-high vacuum sealing, bakeable design, low particle generation, reliable pneumatic actuation, long service life, SEMI-compliant for fab environments
Typical applications: Semiconductor wafer processing, PVD/CVD systems, thin-film coating, vacuum deposition chambers, R&D vacuum systems
Lifecycle: Active product, 10+ years availability, VAT global support network
