Description
HEIDENHAIN 1120314-01
Precise manual axis control for CNC machine setup and operation
| Brand | HEIDENHAIN |
| Model | 1120314-01 |
| Voltage | 5V DC |
| Country of Origin | Germany |
| Weight | 0.4 kg |
| Dimensions | 110x110x75 mm |
| Warranty | 6 months |
| Certifications | CE, RoHS |
| SKU / MPN | 1120314-01 |
| What’s in the box | Handwheel unit, mounting hardware, connection cable, user documentation |
| Handwheel type | Manual pulse generator |
| Resolution | 100 pulses/rev |
| Switchable axes | X/Y/Z/spindle |
| Feed selection | x1 / x10 / x100 |
| Protection rating | IP54 |
| Interface | HEIDENHAIN TNC connector |
Key benefits: High-resolution pulse generation, rugged industrial design, ergonomic grip, reliable HEIDENHAIN compatibility
Typical applications: CNC machine setup, manual axis jogging, tool change, production cell positioning
Lifecycle: Active product, long-term availability and service support
